Mechanical Unit Operation Laboratory

Mechanical Unit Operation Labaratory

Transmitted Light Microscope

Used to analysis the size of very fine particles.

Screen Analysis

Used to determine particle-size distribution before and after grinding and to characterize the particles in terms oftheir mean diameter.

Jaw Crusher

Uses compressive force for breaking of hard particle.

Disk Mill

used for grinding and to change hard material into soft.

Batch Sedimentation study Apparatus

Used to determine the effect of initial concentration on sedimentation and to critical velocity of the particle in each sedimentation jar by constructing a settling curve.

ContinuousSedimentation Apparatus

Used to determine the settling efficiency with &withoutbaffleandtounderstandtheeffectofbafflelocation on sedimentation efficiency

Fluid Mixing Apparatus

Used to observe how different types of impellerturning at different speeds influence the rate ofdispersionofsolids mixesthroughouttheliquid.
